Snapmaker 2.0 Enclosure & Air Purifier

Snapmaker 2.0 外罩

Notice: The specifications listed might be slightly changed in any meaningful way when we refine these products.


General
General	Dimensions
	Air Inlet Diameter	70 mm
	Air Volume	150 m³/h
	Cable Length	2,000 mm
	Clamp Diameter	65–89 mm
	Filter Cartridge Dimensions (W × D × H)	191 × 229 × 308 mm
	Filter Cartridge Lifespan[1]	Approx. 3 months
	Filter Cartridge Weight	2.4 kg
	Filtration Efficiency (0.3–0.5 μm)[2]	95.9%
	Hose Dimensions (Diameter × L)	75 × 2,000 mm
	Input Voltage	AC 100 V – 240 V
	Main Unit Dimensions (W × D × H)	240 × 271 × 420 mm (With Air Oulet Connecter) 240 × 240× 420 mm (Without Air Oulet Connecter)
	Main Unit Weight	8.8 kg
	Maximum Noise (With Hose)	65 dB
	Package Dimensions (W × D × H)	316 × 360 × 595 mm
	Package Weight	12.7 kg
	Power Cord Length	2,000 mm
	Rated Current	5 A
	Rated Power	120 W
	Rated Voltage	24 V DC
	Operating Temperature	0℃–35℃
	Storage Temperature	-4℃–45℃
	Outer Shell Material	Aluminum alloy
	Approvals	CE, FCC, UL62368, IC, RCM, ROHS, WEEE

Notice: The specifications listed might be slightly changed in any meaningful way when we refine these products.

[1] This data is obtained under the condition of typical laser use, and is for reference only.

[2] 0.3 μm responds to the worst case. Particles that are larger or smaller can be filtered with even higher efficiency.
